PTFE Piston Seals SPGW
PTFE Piston Seals Hydraulic SPGW
PTFE piston seals hydraulic offer superior sealing, providing long-lasting protection against leaks in high-pressure systems. These seals are designed for durability and effective performance, ensuring smooth operation in various industrial hydraulic applications.
Min.Order Quantity: 1 Set or 1 Bag
Supply Ability: 1000 Sets per Week
Delivery Time: 5-7 days for samll order
Seals Hydraulic SPGW Applications:
Advantages:
– Smooth operation without stick-slip effect during startup
– Low friction and high wear resistance contribute to an extended service life
– Minimal static and dynamic friction coefficients allow for high-speed performance
– Simple groove design enables the use of a one-piece piston
– Compatible with most hydraulic fluids
– Available for cylinder diameters up to 500 mm
| TYPE | D1 | d1 | L1 | ORDER SIZE | TYPE | D1 | d1 | L1 | ORDER SIZE | |
| JSPGW | 50 | 36 | 8.5 | 50*36*8.5 | JSPGW | 200 | 177 | 15.5 | 200*177*15.5 | |
| JSPGW | 60 | 46 | 8.5 | 60*46*8.5 | JSPGW | 220 | 197 | 15.5 | 220*197*15.5 | |
| JSPGW | 63 | 48 | 10.5 | 63*48*10.5 | JSPGW | 225 | 202 | 15.5 | 225*202*15.5 | |
| JSPGW | 65 | 50 | 10.5 | 65*50*10.5 | JSPGW | 230 | 207 | 15.5 | 230*207*15.5 | |
| JSPGW | 70 | 55 | 10.5 | 70*55*10.5 | JSPGW | 235 | 212 | 15.5 | 235*212*15.5 | |
| JSPGW | 75 | 60 | 10.5 | 75*60*10.5 | JSPGW | 240 | 217 | 15.5 | 240*217*15.5 | |
| JSPGW | 80 | 66 | 10.5 | 80*66*10.5 | JSPGW | 250 | 222 | 17 | 250*222*17 | |
| JSPGW | 85 | 70 | 10.5 | 85*70*10.5 | JSPGW | 255 | 227 | 17 | 255*227*17 | |
| JSPGW | 90 | 75 | 10.5 | 90*75*10.5 | JSPGW | 260 | 232 | 17 | 260*232*17 | |
| JSPGW | 95 | 80 | 10.5 | 95*80*10.5 | JSPGW | 265 | 237 | 17 | 265*237*17 | |
| JSPGW | 100 | 85 | 12 | 100*85*12 | JSPGW | 270 | 242 | 17 | 270*242*17 | |
| JSPGW | 105 | 90 | 12 | 105*90*12 | JSPGW | 275 | 247 | 17 | 275*247*17 | |
| JSPGW | 110 | 95 | 12 | 110*95*12 | JSPGW | 280 | 252 | 17 | 280*252*17 | |
| JSPGW | 115 | 100 | 12 | 115*100*12 | JSPGW | 300 | 272 | 17 | 300*272*17 | |
| JSPGW | 120 | 105 | 12 | 120*105*12 | JSPGW | 320 | 292 | 17 | 320*292*17 | |
| JSPGW | 125 | 102 | 15.5 | 125*102*15.5 | JSPGW | 80 | 65 | 12 | 80*65*12 * | |
| JSPGW | 130 | 107 | 15.5 | 130*107*15.5 | JSPGW | 90 | 75 | 12 | 90*75*12 * | |
| JSPGW | 135 | 112 | 15.5 | 135*112*15.5 | JSPGW | 100 | 85 | 12 | 100*85*12 * | |
| JSPGW | 140 | 117 | 15.5 | 140*117*15.5 | JSPGW | 110 | 95 | 12 | 110*95*12 * | |
| JSPGW | 145 | 122 | 15.5 | 145*122*15.5 | JSPGW | 115 | 100 | 12 | 115*100*12 * | |
| JSPGW | 150 | 127 | 15.5 | 150*127*15.5 | JSPGW | 120 | 100 | 12.5 | 120*100*12.5 * | |
| JSPGW | 160 | 137 | 15.5 | 160*137*15.5 | JSPGW | 125 | 105 | 15.5 | 125*105*15.5* | |
| JSPGW | 165 | 142 | 15.5 | 165*142*15.5 | JSPGW | 130 | 115 | 12.5 | 130*115*12.5 * | |
| JSPGW | 170 | 147 | 15.5 | 170*147*15.5 | JSPGW | 150 | 135 | 18 | 150*135*18 * | |
| JSPGW | 180 | 152 | 15.5 | 180*152*15.5 | JSPGW | 160 | 143 | 1.5 | 160*143*1.5 * | |
| JSPGW | 185 | 162 | 15.5 | 185*162*15.5 | JSPGW | 170 | 154 | 17 | 170*154*17 * | |
| JSPGW | 190 | 167 | 15.5 | 190*167*15.5 | JSPGW | 190 | 173 | 12 | 190*173*12 * | |
| JSPGW | 195 | 172 | 15.5 | 195*172*15.5 | JSPGW | 230 | 210 | 15 | 230*220*15 * |
